Drum type drying equipment
1. working principle The drum of the drum drying oven is a cylinder body with slight inclination and can rotate. Wet materials enter from the upper part of one end and dry materials are collected from the lower part of the other end. Hot air enters from the feed end or the discharge end and is discharged from the upper part of the other end. 2. performance characteristics The water evaporation capacity of the drum dryer is generally 30-80kg/m3 · h; it increases with the increase of the hot air temperature and changes with the moisture properties of the material. The equipment runs smoothly and reliably, with no wearing parts, few faults and long service life, and is widely used in various drying industries. 3. scope of application 1, from the raw material form, can be free flowing powder, granule, flake, fiber and other materials for drying. 2. From the scope of application of materials, it is widely used in the drying of biomass energy, mineral products, building materials, chemical products, compound fertilizer, organic powder, feed, wine trough, starch residue, corn residue, soybean residue, etc. 3. From the mechanism of the drum dryer, it can be divided into direct, indirect heating, vent pipe heating, steam pipe indirect heating, duplex heating and other structural forms. 4, from the drying temperature, can be selected from the range of 60 ℃-600 ℃, in principle, the higher the temperature, the higher the evaporation intensity.
Key words:
Drum type drying equipment
Classification:
Product Description
1. working principle
The drum of the drum drying furnace is a slightly inclined and rotatable cylinder. Wet materials enter from the upper part of one end and dry materials are collected from the lower part of the other end. Hot air enters from the feed end or the discharge end and is discharged from the upper part of the other end.
2. performance characteristics
The water evaporation capacity of the drum dryer is generally 30-80kg/m3 · h; it increases with the increase of hot air temperature and changes with the moisture properties of the material.
The equipment runs smoothly and reliably, with no wearing parts, few faults and long service life, and is widely used in various drying industries.
3. scope of application
1, from the raw material form, can be free flowing powder, granule, flake, fiber and other materials for drying.
2. From the scope of application of materials, it is widely used in the drying of biomass energy, mineral products, building materials, chemical products, compound fertilizer, organic powder, feed, wine trough, starch residue, corn residue, soybean residue, etc.
3. From the mechanism of the drum dryer, it can be divided into direct, indirect heating, vent pipe heating, steam pipe indirect heating, duplex heating and other structural forms.
4, from the drying temperature, can be selected from the range of 60 ℃-600 ℃, in principle, the higher the temperature, the higher the evaporation intensity.
